Mimosa C5c With POE (Single Unit)
Mimosa C5c With POE (Single Unit)
Regular price
Rs.40,500.00 PKR
Regular price
Rs.106,000.00 PKR
Sale price
Rs.40,500.00 PKR
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Order on WhatsApp
C5c has been designed specifically to handle long-range backhaul (PTP), point-to-multipoint (PTMP) GigaPoP links, and PTMP MicroPoP links impaired by vegetation. Connectorized by design, the C5c mates with many popular antennas, delivering 700 Mbps of TCP throughput.
| Performance | |
| Max Throughput | PTP/PTMP: 700 Mbps IP (866 Mbps PHY) |
| Wireless Protocols | WiFi Interop Mimosa SRS |
| Modes | PTMP Client PTP Backhaul |
| Radio | |
| MIMO & Modulation | 2x2:2 MIMO OFDM up to 256 QAM |
| Bandwidth* | 20/40/80 MHz channels tunable to 5 MHz increments for Mimosa SRS; Tunable to standard WiFi channels for WiFi Interop |
| Frequency Range | PTMP: 4900-6400 MHz*** PTP: 4900-6400 MHz Restricted by country of operation *new* US/FCC 5600-5650 MHz support FCC DFS (U-NII-2a, U-NII-2c) availability pending certification |
| Max Output Power | 27 dBm |
| Sensitivity ( MCS 0 ) | -87 dBm @ 80 MHz -90 dBm @ 40 MHz -93 dBm @ 20 MHz |
| Power | |
| Max Power Consumption | 9.2 W |
| System Power Method | Passive PoE (24-56 VDC) |
| PoE Power Supply | Passive POE compliant, 48-56 V Power over Ethernet supply (Not Included) |
| Physical | |
| Dimensions | Depth 44 mm (1.73") Width 65 mm (2.56") Height 188.4 mm (7.42") |
| Weight | 295 grams (10.4 oz) |
| Mounting | Single pole strap |
| Connector Type |
RP-SMA (x2) |
