Cisco Nexus N3K-3164Q Switch

Main benefits

The Cisco Nexus 3164Q provides the following:

●      Wire-rate Layer 2 and 3 switching on all ports up to 5.12 Terabits per second (Tbps) and up to 3.8 billion packets per second (bpps).

●      Rich Programmability, with support for NX-API, Linux Containers, XML/JavaScript Object Notation (JSON) APIs, Openstack plugin, Python, and Puppet/Chef configuration and automation tools.

●      High Performance and Scalability with 6 core CPU, 16GE DRAM and 64 GB SSD, with 48 Mbytes of dynamic buffer allocation. Ideal for massively scalable data centers and big data applications.

●      Flexibility

◦    The QSFP port can be configured to work as four 10-Gbps ports, offering deployment flexibility, up to a maximum of 256 10G ports.

◦    The Cisco Quad Small Form-Factor (QSFP) 40-Gbps Bidirectional (BiDi) Transceiver technology allows the reuse of existing 10G cablings, a smooth transition from 10 to 40 Gigabit Ethernet infrastructures in data centers.

◦    Both fiber and copper cabling solutions for both 10-Gbps and 40-Gbps, with the SFP options of Bidi, AOC, SR4 fiber optics.
